Cub Cadet 364, 365, 365L

47
Model 364
14
15
16
17
18
19
20
1
3
2
4
5
6
4
7
8
9
7
10
11
12
13
REF.
NO.
PART
NO. DESCRIPTION
1. 712-0251 Retainer Nut 3/8-16
2. 603-0720B Frame Assembly
3. 712-0455 Retainer Nut 3/8-16
4. 712-0431 Flange Lock Nut 3/8-16
5. 710-0216 Hex Cap Screw 3/8-16 x .75
6. 710-3144 Hex Cap Screw 3/8-16 x 2.0
7. 712-3004A Flange Lock Nut 5/16-18
8. 736-0258 Flat Washer .385 x 1.0 x .135
9. 749-3087 Upper Bumper Tube
10. 749-3089 Lower Bumper Tube
11. 736-0451 Washer .320 ID x .93 OD
12. 703-3504 Bumper Bracket
13. 710-1250 Carriage Bolt 5/16 x 1.5
14. 710-0521 Hex Cap Screw 3/8-16 x 3.0
15. 710-0859 Hex Cap Screw 3/8 - 16 x 2.5
16. 719-3130 Counter Weight
17. 726-0298 End Cap
18. 603-0620A Bumper Ass’y
19. 736-3004 Flat Washer .406 ID x .875 OD
20. 712-0431 Flange Lock Nut 3/8-16
REF.
NO.
PART
NO. DESCRIPTION
