48
Models 365 & 365L
1
3
2
4
5
6
4
7
8
9
7
10
11
12
13
REF.
NO.
PART
NO. DESCRIPTION
1. 712-0251 Retainer Nut 3/8-16
2. 603-0720B Frame Assembly
3. 712-0455 Retainer Nut 3/8-16
4. 712-0431 Flange Lock Nut 3/8-16
5. 710-0216 Hex Cap Screw 3/8-16 x .75
6. 710-3144 Hex Cap Screw 3/8-16 x 2.0
7. 712-3004A Flange Lock Nut 5/16-18
8. 736-0258 Flat Washer .385 x 1.0 x .135
9. 749-3062 Upper Bumper
10. 749-3061 Lower Bumper Tube
11. 736-0451 Washer .320 ID x .93 OD
12. 703-3504 Bumper Bracket
13. 710-1250 Carriage Bolt 5/16 x 1.5
14. 710-0520 Hex Cap Screw 3/8-16 x 1.5
15. 736-3004 Flat Washer .406 ID x .875 OD
16. 603-0620A Front Bumper
17. 726-0298 End Cap
18. 712-0431 Flange Lock Nut 3/8-16
REF.
NO.
PART
NO. DESCRIPTION
