-23-

4WD TRACTION DRIVE

REF.

NO.

PART

NUMBER CODE DESCRIPTION QTY.

1 603-0906 Pin Assembly, 2 Speed .................. 1

2 710-0573 Screw, Hex Cap Lock, ....................

5/16-18 x 1.25 GR5

3 710-3006 Screw, Cup Set, 5/16-18 x 3/8 ....... 1

4 711-1339 Shaft, Motor .................................... 1

5 711-1344 Shaft, Pinion, 16T ........................... 1

6 711-1372 Shaft, 4WD ..................................... 1

7 711-1397 Shaft, 2 Speed Actuator ................. 1

8 715-0159 Pin, Spirol, 3/16 x .875 ................... 1

9 716-0185 Ring, Retaining ............................... 1

10 716-0384 Ring, Retaining ............................... 1

11 716-0387 Ring, Retaining ............................... 1

12 716-0393 Ring, Retaining ............................... 1

13 716-0396 Clip, Rotor ...................................... 1

14 717-3472 Gear, Drive Pinion, LO 24T:17T .... 1

15 717-3473 Gear, Drive Pinion, HI 33T: 17T ..... 1

16 717-3480 Gear, Drive, LO:59T; HI 50T .......... 1

17 717-3484 Clutch, Overrunning ....................... 1

18 718-0674 Cover, Front ................................... 1

19 718-0678 Spacer, Drive .................................. 1

20 718-3116 Collar, 2 Speed ............................... 1

21 721-0496 Seal, Oil .......................................... 1

22 721-0501 O-Ring ............................................ 1

23 721-0507 Seal, Oil .......................................... 1

24 732-0863 Spring, Detent ................................ 1

25 736-0715 Washer, Thrust ............................... 1

26 741-0862 Ball, Detent ..................................... 1

27 741-1106 Bearing, Ball ................................... 1

28 741-1107 Bearing, Ball ................................... 1

29 741-1109 Bearing, Angular Contact Ball ........ 1

30 741-1112 Bearing, Thrust ............................... 1

31 741-3037 Bearing, Ball ................................... 1

32 741-3057 Bearing, Ball ................................... 1

33 741-3118 Bearing, Sleeve .............................. 2

34 748-3096 Yoke, 2 Speed ................................ 1
