INSTRUMENTS/CONTROLS
20
2. ENGINE COOLANT TEMPERATURE GAUGE
The gauge indicates the coolant
temperature when the starter key
switch is in ON position.
If the engine overheats, the pointer
moves right into H position area.
In this case, run the engine at
1500 RPM without load until the
pointer moves left out from H
position area. If the pointer still
stays in the H position area, stop
the engine immediately and check
for the cause.
3. FUEL GAUGE
The meter shows how much fuel is in the tank.
NOTE: The pointer can be in
any position when the starter
key switch is in the OFF position.
4. TURN SIGNAL INDICATORS The LH indicator on the
TACHOMETER will operate when
the turn signal switch is turned to
the left. The RH indicator will
operate when the switch is turned
to the right. Both indicators will
operate ON and OFF when Hazard
switch is pushed down.
