INSTRUMENTS/CONTROLS
35
OPERATORS SEAT
The seat can be adjusted in 5 fore/aft position by the lever located under
the RH side of the seat.
The seat is adjustable fore and aft by moving a lever.
1. Move the lever upward.
2. Move the seat rearward or forward to
the required position then release the
lever.
3. Push the seat rearward to make sure
that the lock is engaged.
STEERING COLUMN TILT
The steering wheel angle can be adjusted
in three positions by the lever located under
the steering column.
To adjust the position of the steering wheel,
use following procedure.
1. Move the lever fully downward to
disengage the latch from the column.
2. Move the steering wheel rearward of
forward to the required position, then
return the lever upward to lock the
steering column.
3. Make sure that the lock is engaged.
STEERING
COLMN TILT
LEVER
STEERING
COLMN TILT
LEVER
SEAT
ADJUSTING
LEVER
SEAT
ADJUSTING
LEVER
