INSTRUMENTS/CONTROLS
19
INSTRUMENTS AND INDICATORS
1. TACHOMETER AND HOURMETER
The tachometer shows the
engine speed in revolutions per
minute (RPM). A symbol on the
face indicates the correct Power
Takeoff (PTO) operating speed.
The hour meter shows the hours
and tenths of hours that the engine
has operated at an average RPM.
Yellow line [A] shows the 540 rpm of the Rear
PTO speed.
Yellow line [B] shows the 2000 rpm of the MID
PTO speed.
[A]
[B]
