OPERATING INSTRUCTION
50
POWER TAKEOFF (PTO)
Mid PTO (OPTION)
The Mid PTO has a 25.4 mm
(1 inch) diameter 15 spline
output shaft.
ENGAGE THE MID PTO AS
FOLLOWS:
1. Push the clutch pedal fully.
2. Move the Mid PTO control
lever to the ON position.
3. Release the clutch pedal
slowly.
DISENGAGE THE MID PTO
AS FOLLOWS:
1. Push the clutch pedal fully.
2. Move the Mid PTO control
lever to the OFF (Engine Start)
position.
NOTE: Keep the Mid PTO
control lever in the OFF (Engine Start)
slot when starting the engine and when
the PTO is not being used.
3. Release the clutch pedal.
The following table shows the required engine speed to get the required
Mid PTO output shaft speed.
Mid PTO Output
Shaft Speed
2000 RPM
Required
Engine Speed
2526 RPM
MID PTO
LEVER
MID PTO
LEVER
CLUTCH
PEDAL
CLUTCH
PEDAL
