FIELD OPERATION
61
Hitch Control Lever
The hitch control lever is used to raise or lower the implement mounted to
the three point hitch. To raise the hitch, move the lever to the rear. To lower
the hitch, move the lever forward.
Adjustable stops are provided for use whenever it is desirable to return the
hitch control lever to the same operating position.
IMPORTANT: Position of the raise stop should not be set so rearward that
insufficient free play of the lift arms is available at the highest position
when hitch control lever is moved to the raise stop.
HITCH CONTROL LEVER
STOP
STOP
HITCH
CONTROL
LEVER
RAISE STOP
LOWER STOP
LOWER
RAISE
