Hydraulic System 1

2 P/C System (Position Control)

No.PartsNo.Parts

1 Knob 2 Nut

3 Spring Pin 4 Screw

5Ring 6Washer

7 Spring 8 Sleeve

9 O-ring 10 O-ring

11 O-ring 12 Ball

13 Spring 14 Lift Arm

15 Pin 16 Screw

17 Power Arm 18 Piston Rod

19 Bush 20 Piston

21 O-ring 22 Ring

Flowcontrolvalve

Liftarm

Adjuster

StopperA

PClever

StopperB

Punchmark

5-10mm{0.197-0.591in}

Upperlimit

Lowerlimit

GZ3W31-011
