Cub Cadet GT 2521 Parts Manual

-11-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
618-04176 Transmission Assembly, Hydro —
Does not include Ref Nos. 1 and 12
1
1 618-04115 Hub Assembly, Wheel 2
2 619-3071A Housing, RH Transmission 1
3 619-3072 Housing, LH Transmission 1
4 710-0573 Screw, Hex Cap Lock,
5/16-18 x 1.25 GR5
14
5 710-1206 Screw, Hex Wash Hd. Tapp,
1/4-20 x 2.375
2
6 710-1633 Screw, Plug, M14 x 1.5 x .827 1
7 710-3144 Screw, Hex Cap Lock,
3/8-16 x 2.0 GR5
4
8 711-1052A Shaft, Cross, .50 x 3.005 2
9 711-1385A Shaft, Output, 9T 1
10 711-04233 Shaft, Axle 2
11 712-0273 Nut, Hex Nylon Lock, 5/16-24 1
12 710-3119 Screw, Hex Cap Lock,
3/8-16 x .75 GR5
2
13 716-04032 Ring, Retaining 4
14 716-0204 Ring, Retaining 2
15 717-0678 Pad, Brake 2
16 717-0682 Plate, Puck 1
17 717-1446 Gear, Miter, 10T 4
18 717-04102 Gear, Miter, 14T 2
19 717-1568A Gear, Differential Spur, 60T 1
20 717-3449 Gear, Bevel, 54T 1
21 719-0375A Housing, Differential w/Thru Holes 2
22 712-3020 Nut, Hex Insert Jam GR5, 3/8-16 4
23 721-0523 Seal, Oil, 1.0 x 2.047 x .2755 3
24 726-0324 Clamp, Hose 1
25 731-1480 Vent, Plastic 1
26 731-1481 Cap, Plastic Vent 1
27 732-0925 Spring, Torsion 1
28 735-0277A Grommet, Rubber, .75 x 1.063 1
29 735-0279 Grommet, Rubber, .362 x .56 1
30 736-0371 Washer, Flat, .343 x .88 x .062 1
31 736-0615 Washer, Thrust, 1.007 x 1.542 x .03 1
32 737-3092 Fitting, Tube 1
33 741-0343 Pin, Brake Actuating 2
34 741-3114 Bearing, Ball (6205-1) 6
35 750-3346 Spacer, Axle, 1.007 x 1.665 x .141 1
36 750-3358 Spacer, Axle, 1.007 x 1.665 x .989 1
37 751-0588-8 Tube, Transmission Breather 1
38 761-0207A Yoke, Brake 1
39 761-0208 Bracket, Brake Anti Rotation 1
40 761-0215 Disc, Brake 1
41 761-3074 Arm, Brake Actuater 1
42 736-0227 Washer, Flat, .39 x 1.5 x .134 2
759-3958
737-3120
737-3121
Sealant, Loctite Black, 5.3 oz. Tube
Drive System Fluid Plus - Quart
Drive System Fluid Plus - Gallon
1
5.5
AR
HYDRO TRANSMISSION
