Cub Cadet GT 2521 Parts Manual

-8-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0642 Screw, Hex Wsh Hd Tapp, 1/4-20 x .75 2
2 710-3170 Screw, Ball, 5/16-18 x.56 1
3 712-0271 Nut, Hex Sems, 1/4-20 1
4 712-3004A Nut, Hex Flange Lock, 1/4-20 1
5 714-0101 Pin, Internal Cotter 1
6 714-0104 Pin, Internal Cotter 1
7 727-3090 Cylinder, Damper 1
8 732-3118 Spring, Extension, 3/8 OD x 1.44 1
9 738-0560 Bolt, Shoulder, .374 Dia x 1.375 1
10 747-3304 Rod, Front Control 1
11 647-3003 Rod, Rear Hydro Control 1
12 748-3070 Plate, Cruise 1
13 750-0434 Spacer, Split Tubing, .375 ID x 1.04 1
TRANSMISSION CONTROLS
13
12
11
10
9
8
7
5
6
4
3
1
2
