-7-

REF.

NO.

PART

NUMBER DESCRIPTION QTY.

1 603-0064 Arm Assy, Lower Steering 1

2 603-0250 Segment Assy, 18T Steering 1

3 619-04079

737-3000

748-0108

748-3007A

Housing Assy,

Fitting, Grease, 3/16 Drive Type

Bearing, Flange, .503 ID

Bearing, Bronze Flange, .75 ID

4 631-04008 Wheel, Steering, Soft Grip 1

5 710-0751 Screw, Hex Cap, 1/4 - 20 x .62, GR5 2

6 710-1260A Screw, Hex Wash. Hd. Tapp

5/16 - 18 x .75

7 712-0237 Nut, Hex Center Lock, 5/16-18 1

8 712-0711 Nut, Hex Jam, 3/8-24 GR2 4

9 712-3012 Nut, Hex Slotted, 1/2-20 GR5 1

10 712-3027 Nut, Hex Flange Lock, 1/4-20 2

11 712-3054 Nut, Hex Lock, 3/8-24 GR5 4

12 714-3004 Pin, Cotter, 3/32 Dia x 1.25 1

13 717-04086 Pinion, Steering 1

14 722-3019 Gasket, Steering 1

15 723-0156 Joint, Ball, 3/8-24 4

16 731-04532 Cover, Steering Wheel 1

17 736-0272 Washer, Flat, .510 x 1 x .06 Thk 1

18 736-0351 Washer, Flat, .760 x 1.5 x .03 Thk 1

19 736-04062 Washer, Flat, .344 x 1.5 x .1 Thk 1

20 736-0921 Washer, Lock, 1/2 1

21 736-3013 Washer, Flat, .531 x 1 x .027 Thk 1

22 738-04064 Shaft, Steering 1

23 741-3025 Bearing, Flange 1

25 747-3171 Rod, Tie 2

STEERING

Cub Cadet GT 2521 Parts Manual
