Cub Cadet GT 2521 Parts Manual

-28-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 BS-805101 Seal, Oil (Magneto Side) 1
2 BS-806377 Gasket, Cylinder Head 2
3 BS-691684 Gasket, Crankcase 1
4 BS-805049 Seal, Oil (PTO Side) 1
5 BS-690950 Gasket, Intake 1
6 BS-806418 Gasket, Intake 2
7 BS-692087 Gasket, Air Cleaner 1
8 BS-690681 Seal, O-Ring (Oil Pump) 1
9 BS-692154 Seal, O-Ring (Crankcase Cover) 1
10 BS-690690 Seal, O-Ring (Oil Pump Screen) 1
11 BS-691963 Seal, Valve 2
12 BS-692063 Gasket, Oil Adapter 1
13 BS-806039 Gasket, Rocker Cover 2
14 BS-808617 Gasket Set, Engine 1
15 BS-808816 Kit, Carburetor Overhaul 1
16 BS-808257 Kit, Idle Mixture 1
17 BS-693711 Gasket, Carburetor Body 1
18 BS-690882 Pin, Float Hinge 1
19 BS-808798 Valve, Float Needle 1
20 BS-806438 Jet, Main (Standard) Cylinder #1 1
21 BS-806375 Nozzle, Carburetor 2
22 BS-690722 Seal, Choke/Throttle Shaft 1
23 BS-691516 Cap, Limiter 1
24 BS-808619 Gasket Set, Valve 1
25 BS-806439 Jet, Main (Standard) Cylinder #2 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
GASKET SETS AND CARBURETOR OVERHAUL KIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
2
13
6
11
24
25
