-18-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0132 Rod, Quick Attach 1
2 603-0328C Frame 1
3 703-3453
777I20296
777S30265
Drawbar
Graphic, Transmission Release Lever
Graphic, Transmission Oil
1
1
1
4 703-2577 Bumper 1
5 710-0623 Screw, Hex Wsh Hd Tapp 3/8-16 x .75 2
6 710-1260A Screw, Hex Wsh Hd Tap 5/16-18 x .75 10
7 710-3261 Screw, Hex Cap, 3/8-16 x 7.0 1
8 712-0431 Nut, Hex Flange Lock, 3/8-16 1
9 712-3027 Nut, Hex Flange Lock, 1/4-20 2
10 726-0211 U-Nut, 5/16-18 6
11 732-3002 Spring, Latch 1
12 738-0255 Bolt, Shoulder 2
13 750-04198 Spacer, Idler, .411 x .720 x 3.67 2
14 756-3045 Pulley, Idler 2
15 732-0970 Belt Guide 1
FRAME AND DRAWBAR
13
To Next Page
