Cub Cadet GT 2521 Parts Manual

-37-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0031A Bracket, Caster Wheel 2
2 603-0110 Spindle Assy, RH Front 1
3 603-0111 Spindle Assy, LH Front 1
4 903-0183A Plate Assy, Mounting 1
5 703-2248 Bracket, Front Lift 1
6 603-0203 Handle, Tension 1
7 703-1890 Wheel, Ball w/Fitting, 5 in 4
737-3000 Fitting, Lube, 3/16 Drive 4
8 703-2072 Strap, Mounting 2
9 703-2081A Channel, LH Caster 1
10 703-2083 Channel, RH Caster 1
11 703-2094 Caster Assembly, Front 2
12 703-2096B Guard, LH Belt 1
13 703-3240 Guard, RH Belt 1
14 703-2121A Stop, Chute Deflector 1
15 703-2161 Baffle, Rear Inner 1
16 703-2192 Guard, Finger 1
17 703-2479 Bracket, Front Roller 1
18 703-2559 Bracket, Handle Stop 1
19 703-2607 Baffle 1
20 710-0347 Screw, Cap, 3/8-16 x 1.75 GR5 2
21 710-3001 Screw, Cap,3/8-16 x .88 GR5 2
22 710-3008 Screw, Cap, 5/16-18x .75 GR5 1
23 710-3178 Bolt, Carriage, 3/8-16 x .75 GR5 24
24 710-3232 Screw, Thumb Adj, 5/16-18 x 1 4
25 711-3266 Pin, Clevis w/Ball Detent 4
26 711-3312 Axle, Deck Caster 2
27 711-3314 Pin, Roller, 1/2 Dia x 7.31 1
28 711-1762 Pin, Hinge, .375 Dia x 14.06 1
29 712-0431 Nut, Hex Flanged Lock, 3/8-16 32
30 712-3004A Nut, Hex Flanged Lock, 5/16-18 1
31 712-3016 Nut, Hex Top Lock, 5/8-11 GR5 2
32 712-3027 Nut, Hex Flange Lock, 1/4-20 1
33 712-3048 Nut, Hex Jam, 1/2-13 GR5 2
34 712-3083 Nut, Hex Top Nylon Lock, 1/2-13 2
35 714-0115 Pin, Cotter, 1/8 Dia x 1 1
36 714-0145 Pin, Int. Cotter, .092 Dia. x 1.63 1
37 715-3003 Pin, Spirol, 3/16 x .75 2
38 726-0211 U-Nut, 5/16-18 4
39 726-3045 Plug, Button 2
40 731-3005 Roller 1
41 731-3131A Deflector, Chute 1
42 732-0478 Spring, Extension, .75 OD x 6.12 1
43 732-3070 Spring, Torsion 1
44 732-3094 Spring, Compression, .63 ID x 2 1
45 732-0861 Spring, Extension, 1.25 OD x 7.2 1
46 732-3126 Spring, Extension, .91 OD x 7.33 2
47 732-3127 Spring, Compression 2
48 736-0105 Washer, Bell, .380 x .88 x .062 2
49 736-0169 Washer, Lock, 3/8 2
50 736-0174 Washer, Wave, .625 x .885 x .015 2
51 736-0242 Washer, Bell, .340 x .872 x .060 4
52 736-0272 Washer, Flat, .510 x 1 x .060 4
53 736-0290 Washer, Flat, .63 x 1 x .063 2
54 736-3088 Washer, Flat, .635 x 1.585 x .062 2
55 737-3000 Fitting, Lube, 3/16 Drive 2
56 738-0129 Bolt, Shoulder 1
57 738-0143 Bolt, Shoulder, .498 Dia x .340 1
58 738-0507B Bolt, Shoulder, .500 Dia x .434 2
59 738-0572 Bolt, Shoulder, .374 Dia x 1.16 1
60 738-3056 Bolt, Shoulder 2
61 738-3093 Bolt, Step Shoulder 2
62 741-0353 Bearing, Flange 4
63 747-3172B Rod, Front Lift 1
64 747-3188 Pin, Mower Support 2
65 747-3237A Rod, LH Lift Assist 1
66 750-0639 Spacer, .437 ID x .625 OD x .75 2
67 759-3733
777S30014
777S30015
777S30503
Deck Assembly w/Graphics
Graphic, Caution Spring Tension
Graphic, Rider Danger
Graphic, Danger
1
1
1
1
68 777S30145 Graphic, Danger 1
69 710-3168 Bolt, Carriage, 3/8-16 x 1.0 GR5 2
70 736-0921 Washer, Lock, 1/2 2
71 710-0520 Screw, Cap, 3/8-16 x 1.5 GR5 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
48" DECK ASSEMBLY
