Cub Cadet GT 2521 Parts Manual

-5-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0321A Shaft Assy, Brake 1
2 603-0412 Pedal Assy, Reverse 1
3 603-0697 Shaft Assy, Forward/Reverse 1
4 603-0419 Cam Assy, Control 1
5 603-0421A Plate Assy, Disengagement 1
6 703-2570A Pedal, Forward 1
7 703-2573A Pedal, Brake 1
8 703-2804 Plate, Bearing Mounting 2
9 703-2938 Bracket, Reverse Pivot 1
10 703-2941 Bracket, Cruise 1
11 703-2942 Plate, Rod Adjustment 1
12 703-2962 Lever, Cruise 1
13 703-2963 Lever, Brake Lock 1
14 703-2965 Actuator, Reverse Switch 1
15 710-0106 Screw, Hex Cap, 1/4-20 x 1.25 1
16 710-0599 Screw, Hex Wash Hd Tapp 1/4-20 x .5 1
17 710-0623 Screw, Hex Wash Hd Tapp 3/8-16x .75 2
18 710-0642 Screw, Hex Wash Hd Tapp 1/4-20x .75 6
19 710-0796 Screw, Truss Mach, #12 x 1.5 1
20 710-0216 Screw, Hex Cap, 3/8-16 x .75 GR5 2
21 710-3009 Screw, Phil Hd Pan, #10-24 x .75 2
22 711-0415 Pin, Clevis, 3/8 x 1.62 1
23 711-0736 Ferrule, Adjustment, 1/4-20 Thrd 1
24 711-1138 Stud, Actuator 1
25 711-3295 Pin, Clevis, .25 x 2.38 1
26 712-0271 Nut, Hex Sems, 1/4-20 1
27 712-0431 Nut, Hex Flange Lock, 3/8-16 3
28 712-3004A Nut, Hex Flange Lock, 5/16-18 1
29 712-3027 Nut, Hex Flange Lock, 1/4-20 1
30 714-0104 Pin, Internal Cotter, 5/16 Dia x 1.12 9
31 714-0145 Pin, Internal Cotter, 3/8 Dia x 1.62 6
32 715-0114 Pin, Spiral Spring, 1/4 x 1.5 1
33 731-3205 Pedal, Reverse 1
34 731-3206 Knob, Cruise 1
35 731-3207 Knob, Brake Lock 1
36 732-0418 Spring, Extension, .38 OD x 2.1 1
37 732-0463A Spring, Extension 1
38 732-0756A Spring, Torsion 1
39 732-04006 Spring, Extension, .6 OD x 1.34 1
40 732-3099 Spring, Compression, .50 x 2.23 1
41 732-3117 Spring, Switch Actuator 1
42 735-3048 Pad, Forward Foot Control 1
43 735-3049 Pad, Brake Foot 1
44 736-0174 Washer, Wave, .625 x .885 x .015 1
45 736-0349 Washer, Flat, .635 x 1.0 x .020 1
46 736-0463 Washer, Flat, 1/4 x .63 x .051 1
47 738-0145 Shoulder Bolt, .50 OD x .840 1
48 741-3065B Bearing, Hex Flange Split 4
49 741-3073 Bearing, Flange, .375 x .58 x .25 2
50 741-3074 Bearing, Flange, .626 x .93 x .344 3
51 747-3392A Rod, Brake 1
52 747-3219 Rod, Parking Brake 1
54 747-3307 Rod, Cruise 1
55 748-3060 Latch, Cruise 1
56 761-0215 Disc, Brake 1
57 710-1206 Screw, Hex Wash Hd, Tapp,
1/4-20 x 2.375
2
58 712-0273 Nut, Hex Nylon Lock, 5/16-24 1
59 717-0678 Pad, Brake 2
60 717-0682 Plate, Puck 1
61 732-0925 Spring, Torsion 1
62 736-0371 Washer, Flat, .343 x .88 x .062 1
63 741-0343 Pin, Brake Actuating 2
64 761-0207A Yoke, Brake 1
65 761-0208 Bracket, Brake Anti Rotation 1
66 761-3074 Arm, Brake Actuator 1
67 747-3341A Rod, Rear Connecting 1
68 747-3383 Rod, Front Connecting 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
BRAKE AND CONTROL PEDALS
