23se c t i O n 6 — Ma i n t e n a n c e & ad j u s t M e n t s
cap/dipstick from the oil fill tube.
4.
oil drain port. Route the opposite end of the hose into an
appropriate oil collection container with at least a 2.5 quart
capacity, to collect the used oil.
The engine is equipped with either a twist-and-pull drain port or 5.
a tabbed drain port. If your engine has the twist-and-pull
drain go to step a. If your engine is equipped with the
tabbed drain go to step b.
Turn the oil drain valve a. ⁄-turn, then pull outward to
begin draining oil. After the oil has finished draining,
push the end of the oil drain valve back in and turn
⁄turn to secure it back in place Re-cap the end of
the oil drain valve to keep debris from entering the
drain port.
b.
begin draining oil. After the oil has finished draining,
push the end of the oil drain valve back in, until the
tabs click into place. Re-cap the end of the oil drain
valve to keep debris from entering the drain port.
After the oil has finished draining, push the end of the oil drain 6.
valve back in, until the tabs click into place. Re-cap the end
of the oil drain valve to keep debris from entering the drain
port.
Replace the oil filter, and refill the engine with new oil as 7.
Air Cleaner
Spark Plug
The spark plugs should be cleaned and the gap reset once a
plug type and gap specifications.
General Battery Information
WARNING!
the eyes or onto the skin, rinse the affected area
immediately with clean cold water. If there is any
further discomfort, seek prompt medical attention.
If acid spills on clothing, first dilute it with
clean water, then neutralize with a solution of
ammonia/water or baking soda/water.
NEVER connect (or disconnect) battery
charger clips to the battery while the charger is
turned on, as it can cause sparks.
Keep all sources of ignition (cigarettes,
matches, lighters) away from the battery. The gas
generated during charging can be combustible.
As a further precaution, only charge the
battery in a well ventilated area.
Always shield eyes and protect skin and
clothing when working near batteries.
emit explosive gases. Use extreme caution when
handling batteries. Keep batteries out of the reach
of children.
Battery Maintenance
The battery is filled with battery acid and then sealed at
requires some maintenance to ensure its proper life cycle.
terminal sealer, or coat the terminals with a thin coat of
grease or petroleum jelly, to protect against corrosion.
Always keep the battery cables and terminals clean and
free of corrosion.
Avoid tipping. Even a sealed battery will leak electrolyte
when tipped.
WARNING!
emit explosive gases. Use extreme caution when
handling batteries. Keep batteries out of the reach
of children.
Tire Maintenance
weekly. Keep the tires inflated to the recommended pressures.
guidelines:
Do not inflate a tire above the maximum pressure shown
on the sidewall of the tire.
Do not reinflate a tire that has been run flat or seriously
service the tire.
Lubrication
Using a pressure lubricating gun, lubricate the front castor
Oil Filler
Oil Fill Cap/Dipstick
Oil Drain Valve
Oil Fill Tube
Figure 6-1
To Next Page
