FRAME
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 17962 Plate, Switch 1
2 683-04173 Frame Assembly, Lower 1
3 726-0205 Clamp, Hose,.490 Dia. 2
4 710-0224 Screw, Hex Wash. Hd. Tapp, 10-16 x.5 2
5 710-0726 Screw, Self-tapping, 5/16-18, 0.75 13
6 751-0535 Fuel Line 1
7 710-1652 Screw, Hex Wash. Hd. Tapp, 1/4-20 x 0.625 1
8 725-04039 Switch, Interlock 1
9 712-04065 Nut, Nylon Lock, 3/8-16 4
10 710-0607 Screw, Hex Wash. Tapp, 5/16-18 x.5 1
11 783-04329A Bracket, Frame, Seat 1
12 741-04092 Snap Bushing 1
13 732-04035 Spring, Compression, 1.28 OD x 3.125 Lg 2
14 736-0222 Washer, Lock, Ext 1/4 1
16 738-04058 Shoulder Spacer 2
17 738-0143 Shoulder Screw, 3/8-16 2
18 710-3005 Hex Screw 3/8-16 x 1.25 2
19 783-0726D Bracket, Pivot, Support RH 1
20 783-0727C Bracket, Pivot, Support LH 1
21 783-0728 Bracket, Pivot, Bar 1
22 783-04330A Frame, Upper 1
