Culligan CSM Series User Manual

Schematic 35
Cat. No. 01016370
Flow Sensor Meter Schematic (optional)
The MVP controller is capable of detecting the signal from a Hall effect sensor device to provide flow rate information,
totalization and volume based regeneration initiation. The flow meter device is automatically detected when connected to
the controller.
There are several different types of flow measuring devices and differences in the wiring of the devices to the MVP circuit
board do exist. Refer to the following drawing.
Aux
2.5VAC
P9 Power
Aux2
Vlv
P7
Sol
24VAC
P8
Aux1
P5
Aqua
Snsr
Cam
Meter
P1
Flow
P6
P12
Motor
P11
Batt
LCD
Dip Switch
SW6
In
P2
Comm
P3
Comm
Flow
Meter
Cam
P1
In
Aux
P2
Snsr
Aqua
P3
(optional)
2535 & 2536
Signet
Black
Shield
Red
Black Green Red
Paddle Wheel
(optional)
Seametrics
Green Red Black White
To Comm on other board
(Multi-tank only)
To Comm on other board
DUPLEX ALTERNATING
Duplex Alternating Setup
SINGLE OR PROGRESSIVE
Bare
Red Green Black
Red
Black
Wht/Clear
(Connector,
comes with the
standard
2" Autrol Turbine Meter
P/N 01010255
MVP control)
(optional)
K Factor 15
Black
White
Red
K Factor xx
2"Clack Meter
(optional)
K Factor 20
Refer to page 90 for K Factors
Figure 53.
