16 Culligan® Culligan Top Mount (CTM) Water Filters
16 Cat. No. 01029343
Eductor Nozzle and Throat Replacement
Figure 13.
Pull to release plug
Push to secure
CAUTION! Clip was designed to stay attached
to the valve. Do NOT try to detach.
Twist off to remove nozzle and throat
Leave in existing throat, nozzle is
not required for filter applications.
Remove with pliers. Replace with eductor
throat in sizing kit. Lubricate o-rings.
Lubricate o-rings.
Insert fully to
secure.
To Next Page
