Culligan Mark 100 Owner's Guide

Specifications
Culligan
®
Mark 100 Water Conditioners with Time Clock, Aqua-Sensor
®
Device or Soft-Minder
®
Meter
1 Capacities and corresponding salt dosages pertain to low hardness waters. Capacities given are per recharge
2 Measured from top of media to top of inlet fitting (backwashed and drained).
3 Measured from top of underbedding to top of inlet fitting.
4 Backwash at 120 psi (830 kPa).
5 10 minute backwash, 7 lb (3.2 kg) 9” model or 13 lb (5.9 kg) 12” model salt dosage at 30 psi (204 kPa).
9” Model 12” Model
Control Valve 5-cycle, Reinforced Thermoplastic 5-cycle, Reinforced Thermoplastic
Overall Conditioner Height 51 in 51 in
1 295 mm 1 295 mm
Media Tank Dimensions (Dia x Ht) 9 x 45 in 12 x 45 in
229 x 1 143 mm 305 x 1 143 mm
Salt Storage Tank Dimensions (Dia x Ht) 16 x 43 in 18 x 43 in
406 x 1 092 mm 457 x 1 092 mm
18 x 43 in
457 x 1092 mm
Exchange Media, Type and Quantity Cullex
®
Media, 0.86 ft
3
Cullex
®
Media, 1.4 ft
3
Cullex
®
Media, 24.5 L Cullex
®
Media, 40 L
Underbedding, Type and Quantity Cullsan
®
Underbedding, 12 lb Cullsan
®
Underbedding, 30 lb
Cullsan
®
Underbedding, 5.4 kg Cullsan
®
Underbedding, 14 kg
Exchange Capacity 17,500 gr @ 4.0 lb 24,100 gr @ 6.0 lb
@ Salt Dosage Per Recharge
1
1 133 g @ 1.8 kg 1 560 g @ 2.7 kg
23,900 gr @ 8.0 lb 34,500 gr @ 12.0 lb
1 547 g @ 3.6 kg 2 234 g @ 5.4 kg
26,600 gr @ 12.0 lb 41,900 gr @ 18.0 lb
1 722 g @ 5.4 kg 2 713 g @ 8.1 kg
Freeboard to Media
2
16.6-17.6 in 17.5-18.5 in
420-447 mm 444-470 mm
Freeboard to Underbedding
3
39.2 in 38.5 in
996 mm 978 mm
Salt Storage Capacity 250 lb or 375 lb 375 lb
114 kg or 170 kg 170 kg
Rated Service Flow @ Pressure Drop 7.5 gpm @ 15 psi 7.5 gpm @ 15 psi
30 Lpm @ 102 kPa 31 Lpm @ 102 kPa
Total Hardness, Maximum 75 gpg 99 gpg
1 283 mg/L 1 692 mg/L
Total Iron, Maximum 5 ppm 5 ppm
5 mg/L 5 mg/L
Hardness to Iron Ratio, Minimum 8 gpg to 1 ppm 8 gpg to 1 ppm
140 mg/L to 1 mg/L 140 mg/L to 1 mg/L
Operating Pressure 20-125 psi 20-125 psi
140-860 kPa 140-860 kPa
Operating Temperature 33-120°F 33-120°F
1-50°C 1-50°C
Electrical Requirements 120V/60 Hz 120V/60 Hz
Electrical Power Consumption, Min/Max 3 Watts/35 Watts 3 Watts/35 Watts
Drain Flow, Maximum
4
2.0 gpm 3.5 gpm
8 Lpm 14 Lpm
Recharge Time, Average
5
80 min 85 min
Recharge Water Consumption, Average 45 gal 86 gal
170 L 325 L
2 CULLIGAN
®
MARK 100 WATER SOFTENER OWNER'S GUIDE
