Parts List 24
Item Part No. Description
- 01017638 Control Valve Assembly - Medallist Plus
- 01014409 Control Valve Assembly - 3/4” Medallist
1 01013976 Control Valve Body - Medallist Plus
1 00449865 Control Valve Body - 3/4” Medallist
2 00444914 O-ring,ARP# 123, EP, 1.187”x1.375
3 00448126 Plug Body Rear
4 01013083 Seal Pack Assembly
5 00448128 Clip Ret Ss .187” dia
6 01004689 Cul-Flo Bracket
7 P0318383 Screw (10/kit)
8 P0331636 Flow Control #3 Green 3.5 gpm
00331637 Flow Control, Red 4.5 gpm
00401031 Flow Control, Black 5.5 gpm
A0708008 Flow Control, 7.0 gpm, Needs Spacer
01014426 Backwash Spacer
9 01017758 Drain Elbow Assembly w/ O-ring
10 00446475 Plug Hole
11 00447387 Clip, Drain Elbow
12 00448668 Plug Filter Assembly w/ O-ring
15 00445797 Seal, Eductor Port
16 00401022 Cover, Eductor Port
17 P0448687 Screw
20 01014787 Medallist Power Cord
21 01006498 Plug Dome
22 01000372 Bshng Relief
Item Part No. Description
23 01014036 Backplate
24 01013730 Sleeve Eductor Fltr w/ O-rings
26 Drive Motor & Bracket Assembly
24v/60hz
27 P0318452 Screw
28 01012933 Yoke
29 01012926 Bracket
30 01013031 Cam
31 01013043 E-ring
32 01003244 Microswitch
33 P0318455 Screw
34 P1001784 Screw
35 01014172 Circuit Board
36 01014037 Cover
37 01882288 Timer Label
38 01014038 Hinge Pin
39 01882366 Label, Filter
* 01012956 Wall Mount Transformer
* 01014734 Wire Harness (Motor, Switches & Circuit
Board)
* P0451701 Hose Clamp, Drain (25/kit)
* 01013839 Back-up Battery
* 01018760 1-1/4” Bypass Valve Assembly
* 01018425 1” Bypass Valvev Assembly
