Culligan MEDALLIST SERIES Installation And Operation Instructions With Parts List

8 Inch Medallist 10 Inch Medallist 10 Inch Medallist Plus
General
Mineral Tank Size
1
8 x 44 in. 10 x 54 in. 10 x 54 in.
Control 3/4” Power Valve 3/4” Power Valve 1” Power Valve
Timer Electronic Electronic Electronic
Temperature Limits 33-120°F 33-120°F 33-120°F
Water Pressure Limits 20-125 psi 20-125 psi 20-125 psi
Electrical Requirements 24V/60 Hz 24V/60 Hz 24V/60 Hz
Electrical Power Consumption, Min./Max. 3 Watts/35 Watts 3 Watts/35 Watts 3 Watts/35 Watts
Filtr-Cleer
®
Rated Service Flow 7.8 gpm 8.9 gpm 12.0 gpm
@ Initial Pressure Drop @ 15 psi @ 15 psi @ 15 psi
Minimum Practical Filtration Size 10 microns 10 microns 10 microns
Maximum Particulate Matter 150 NTU 150 NTU 150 NTU
Maximum Suspended Solids 150 mg/L 150 mg/L 150 mg/L
Drain Flow, Maximum
3
4.5 gpm 7.0 gpm 7.0 gpm
pH Limitation 6.0 - 9.5 6.0 - 9.5 6.0 - 9.5
Recharge Time
4
80 min. 80 min. 30 min.
Recharge Water Consumption, Av.
5
100 gal. 115 gal. 140 gal.
Freeboard
2
10.5 ± 1 inches 11.5 ± 1 inches 19 ± 1.5 inches
Height Overall 51 in. 63 in. 60 in.
Cullar
®
Rated Service Flow 4.0 gpm 4.0 gpm 6.0 gpm
@ Pressure Drop @ 5.0 psi @ 5.0 psi @ 6.0 psi
Drain Flow, Maximum
3
2 gpm 6.0 gpm 6.0 gpm
pH Limitation 5.0 - 11.0 5.0 - 11.0 5.0 - 11.0
Recharge Time
4
80 min. 80 min. 30 min.
Recharge Water Consumption, Av.
5
53 gal. 83 gal. 110 gal.
Cullar Media Volume 0.75 cu. ft. 1.0 cu. ft. 1.5 cu. ft.
Cullsan
®
Underbedding Media Amount 10 lbs. (.1 ft
3
) 20 lbs. (.2 ft
3
) 20 lbs. (.2 ft
3
)
Freeboard
2
14 ± 1 inches 24 ± 1 inches 24 ± 1.5 inches
Height Overall 51 in. 63 in. 60 in.
Rated Capacity 100,000 gallons 130,000 gallons 180,000 gallons
Cullneu
®
Rated Service Flow 2.7 gpm 4.0 gpm 6.0 gpm
@ Pressure Drop @ 3.0 psi @ 4.0 psi @ 5.0 psi
Drain Flow, Maximum
3
3.5 gpm 6.0 gpm 6.0 gpm
pH Limitation* 5.8 - 6.2 5.8 - 6.2 5.8 - 6.8
Recharge Time
4
80 min. 80 min. 30 min.
Recharge Water Consumption, Av.
5
53 gal. 83 gal. 110 gal.
Cullneu Media Volume 1.0 cu. ft. 1.5 cu. ft. 1.6 cu. ft.
Freeboard
2
11 ± 1 inches 21 ± 1 inches 18 ± 1.5 inches
Height Overall 51 in. 63 in. 60 in.
1 Bottom of tank to top of tank fittings.
2 Backwash at 120 psi line pressure.
3 Backwash at 120 psi line pressure.
4 Factory setting.
5 At factory setting and 120 psi line pressure.
6 Top of media to back top edge of port openings.
* Under dynamic conditions, it may be necessary to mix five parts Cullneu with one part Cullneu C to effectively raise the pH.
Specifications and Limitations
Specifications and Limitations 2
