Machine diagram | Single-pocket JetScan
®
currency scanner | 5
Communication ports
Two RJ45 serial ports are located on the back panel of the machine. Port one is on
top, and port two is on the bottom.
Hopper
Machine is auto-start capable. Feed rollers in hopper
rotate inward.
Entanglement and drawing-in hazard.
Do not operate with exposed long hair, neckties, jewelry or
loose clothing.
The hopper is the area on the top of the machine where notes are placed for
processing. If the machine is congured to auto-start, the rollers and wheels begin
moving as soon as the machine detects notes in the hopper.
Thicknessadjustmentdial
The dial located on the top of the machine adjusts the tightness of the feeder through
which notes pass during operation. The dial has positive and negative adjustment
numbers, with 0 at the center of the adjustment range.
For normal feeding, start with 0 at the top of the dial.
To help reduce the occurrence of doubles or chains, turn the dial to the right, so
a negative number is at the top, decreasing the distance between the rollers.
Turning the dial to the left, so a positive number is at the top, increases the
spacing between the rollers, allowing notes to pass through more easily.
