Diesel Engine Complete Engine
47
Exhaust Manifold
Remove the eight capscrews, exhaust manifold, and
gasket.
Discard the gasket.
Fuel Injection Tubing
Remove the clamp.
Remove the sleeve nuts and the fuel injection tubing
from the fuel injection pump and the cylinder head.
Intake Manifold
Remove the eight capscrews, intake manifold, and air
inlet connection. Remove the grid heated, if equipped.
Remove the four capscrews, air inlet connection, and
o-ring. Discard the o-ring.
00900162
00900163
00900164
