Diesel Engine Complete Engine
48
Spill Tube
Remove the spring hose clamps and hose.
Remove the spill tube.
Injector
CAU
TIO
N
Be careful not to damage the tip of the injector
when removing.
Remove the mounting capscrew, washer, and injector.
NOTE: When removing the injector, clean around
the injector, and insert a blind plug to
prevent dust or dirt from entering the engine.
NOTE: Mark the injectors with tags showing the
cylinder number, and keep it in a safe place.
If there is no abnormality in the injector,
install it in the same position during
assembly.
Rocker Lever Cover
Remove the three capscrews, isolator assemblies,
rocker lever cover, and o-ring.
00900166
00900167
03900075
