Diesel Engine Complete Engine
53
Crankshaft Pulley
Remove the capscrew and mounting plate.
Remove the crankshaft pulley using flange puller,
Part No. 3397890.
Gear Housing Cover
Remove the 17 capscrews and the gear housing
cover.
NOTE: A noise damper is installed on some
engines. The noise damper must be
removed prior to removing the front oil seal.
Remove the front oil seal from the gear housing cover.
00900180
00900212
00900181
00900182
