Diesel Engine Complete Engine
77
Adjusting Valve Clearance
Adjust the valve clearance. Refer to Section 14.
Rocker Lever Cover
Install the o-ring into the rocker lever cover.
Install the rocker lever cover, three capscrews, and
isolator assemblies.
Tighten the capscrews.
Torque Value: 9 N•m [7 ft-lb]
Injector
Coat the injectors with anti-sieze compound, Part No.
3824879, before installation.
CAU
TIO
N
Be careful not to damage the tip of the injector
when installing.
NOTE: When installing the injector, clean around
the injector, and do not allow dust or dirt to
enter the engine.
NOTE: If there is no abnormality in the injector,
install it in the same position during
assembly.
Install the injector, washer, and mounting capscrew.
Tighten the capscrew.
Torque Value: 44 N•m [33 ft-lb]
03900077
03900075
fi9slwb
00900167
