Diesel Engine Complete Engine
82
Insert the power cord into the socket being careful to
align the pins with the sockets of the power cord.
Tighten the retaining nut by hand.
Do not apply power until the cooling system is filled,
and run the engine long enough for the thermostats to
open and ensure all the air has escaped.
Alternator
Install the alternator and capscrew.
Install the spacer, mounting capscrew, and
adjustment plate.
Loosely install the washer and adjustment capscrew.
Fan Pulley
Install the fan pulley.
Position the fan belt (2) into the fan pulley groove,
and loosely tighten the adjustment capscrew (1).
cs900hc
00900159
00900255
00900158
