Maintenance Precautions
Grinder Maintenance
Regular maintenance checks are required to
ensure optimum and reliable operation of
the coffee grinder.
It is VERY IMPORTANT FOR YOUR SAFETY
to follow the guidelines below:
a) If you observe any abnormal operation,
turn off the coffee grinder, unplug it
immediately from the mains outlet, and
contact CUNILL’S Technical Service.
NEVER ATTEMPT TO FIX THE
COFFEE GRINDER YOURSELF.
b) Any possible repairs must be
made by CUNILL’s Technical
Service or by authorized dealer personnel.
c) Do not try to modify the coffee grinder in
any way.
d) Use only ORIGINAL SPARE PARTS
provided by the manufacturer in all
repairwork. (For greater convenience, there
is even a “First-Aid Kit” for urgent repairs
or quick replacement of parts subjected to
greatest wear).
SPARE PARTS
ORI- GINAL-
CUNILL
e) All maintenance work should be done
with the coffee grinder off and unplugged
from the mains.
27
Electrical Maintenance
28
General Maintenance
It is important to check the condition of the
grinding teeth regularly. Wear of these pieces
leads to lower ground coffee quality, more
electrical consumption and hotter running
of the electric motor.
To avoid these affects, the grinding teeth
should be replaced when the coffee grinder
has been used to grind the amount of coffee
beans (in Kilos) specified in the technical
data for each model (section 8).
Replacement of the grinding teeth should be
perfomed by CUNILL’S Technical Service or
by authorized dealer personnel.
Check the state of the power cord, plug and
On/Off switch (11) regularly.
Should you observe any damage
or wear, DO NOT TURN ON
THE COFFEE GRINDER. Keep
it unplugged and immediately
contact CUNILL’s Technical
Service. DO NOT TRY TO
REPAIR IT YOURSELF.
Make regular checks of the coffee grinder’s
different parts - coffee bean hopper (2),
ground coffee feeder (8), exterior of machine,
etc.
Should you observe any damage or wear, DO
NOT TURN ON THE COFFEE GRINDER.
Keep it unplugged and immediately contact
CUNILL’s Technical Service.
07
Technical Specifications
07
Technical Specifications
MARFIL Model
H:610mm L:355mm W:210mm Wei:15Kg
Number of motors: 1
Voltage:230v-110v-Frequency:50Hz-60Hz
Phases: 1(single)-Amperage:1,80A-3,7A
Power:0,18/352
Condenser: 12nf-450v
Speed:1300-1650 Protection degree:IP21
Maximum Continuous Service Time:30min.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 60mm.
Duration of Grinding Wheels:500kg Cof.B.
Hopper Capacity: 2 Kg.
Dispenser Capacity: 600 Gr.
Dispenser adjustment: 5Gr - 12Gr.
Optional: Automatic On/Off function
Minimum Time in Repose: 10 min.
MICHIGAN Model
H: 700mm L:355mm W: 210mm Wei:18Kg
Number of motors: 1
Voltage:230v-110v-Frequency:50Hz-60Hz
Phases: 1(single)-Amperage:3,1A6,82A
Power: 0,50/680
Condenser: 20nf-450v -80nf-400v
Speed:1300-1650 Protection degree:IP21
Maximum Continuous Service Time:30min.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 65mm
Duration of Grinding Wheels:500kg Cof.B.
Hopper Capacity: 2 Kg.
Dispenser Capacity: Bags
Dispenser adjustment: NO
Special Bags
Minimum Time in Repose: 10 min.
RUMBA Model
H: 370mm L: 270mm W: 185mm Wei: 10Kg
Number motors: 1
Voltage: 230v -110v -Frequency: 50Hz-60Hz
Phases: 1(mono) - Amperage:1,15A - 2,53A
Power: 0,10/270
Condenser: 10nf-450v - 40nf-400v
Speed: 1300-1650-G/P: IP21.
Maximum Continuous Service Time: 30 min.
Tempered Steel Grinding Wheels, 60mm.
Duration of Grinding Wheels:500kg Cof.B
Hopper Capacity: 1/2Kg.
Dispenser: Elektronic.
Minimum Time in Repose: 10 min.
