Cunill Classic TRANQUILO - HAWAI - 2 -Cooled Model; MOVIE - BIMOTOR-Cooled Model; Adjusting Ground Coffee Amount Dispensed by the Coffee Grinder; Cleaning Precautions

07
Michigan-bolas
Movie - Silencioso
18
Adjusting Ground Coffee Amount
Dispensed by the Coffee Grinder
20
Cleaning Precautions
You can adjust the ground coffee feeder (8)
to obtain a SMALL MEASURE (minimum 5g.)
up to a LARGE MEASURE (maximum 12 g.)
as follows:
To obtain a SMALLER
Measure:
a) Unplug the grinder.
b) Remove the ground
coffee feeder lid (7).
c) Turn the ground
coffee screw (9) TO THE
RIGHT.
d)Replace the ground coffee feeder lid (7).
To obtain a LARGER Measure:
a)Turn off the coffee grinder using the On/
Off switch (11).
b) Remove the ground coffee screw (9) TO
THE LEFT.
d)Replace the ground coffee feeder lid (7).
The coffee grinder SHOULD NOT BE
OPERATED CONTINUOSLY FOR MORE
THAN 30 MINUTES.
If you observe any abnormal
operation, turn off the coffee
grinder, unplug it immediately
from the mains outlet, and
contact CUNILL’s Technical
Service your dealer.
19
Maximum Operating Time
It is very important to regularly clean the
coffee grinder’s different parts.
To avoid any incidents, you should clean
the machine with the indicated frequency
following these SAFETY GUIDELINES:
a) Before cleaning any part of the coffee
grinder (even the outer shell) make sure you
turn it off using the on/off switch (11) and
unplug the coffee grinder from the mains
outlet.
b) Never clean the coffee grinder using
running water or submerging it in water.
c) Never use abrasive cleaners or chemical
solvents.
t
Frequency: Every 25 days.
a) Unplug the
grinder.
b) Loosen the
lockscrews (3)
which fasten
the hopper to
the adjusment
platen (4) and
remove the
hopper (2).
c) Clean the hopper using a highly diluted
solution of dishwasher liquid in water.
Always wash the hopper by hand, never
place in the dishwasher.
d) Make sure the hopper is completely dry
before re-attaching it and locking the screws
(3).
Cleaning the Hopper
21
Technical Specifications
HAWAI - 2 -“Cooled” Model
H:600mm L:250mm W:210mm Wei:20Kg
Number of motors: 1+ 2motor-fans
Voltage:230v-110v-Frequency:50Hz-60Hz
Phases:1(single)-Amperage:5,75A-12,65A
Power: 0,75/980
Condenser: 90MF-230V -400nf-125v
Speed:1300-1650 Protection degree:IP21
Maximum Continuous Service Time:30min.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 65mm
Duration of Grinding Wheels:500kg Cof.B.
Hopper Capacity: 1/2 Kg.
Dispenser Capacity: Bags
Dispenser adjustment: NO
Special Bags
Minimum Time in Repose: 10 min.
MOVIE - Silencer
MOVIE - BIMOTOR-”Cooled” Model
H:660mm L:460mm W:265mm Wei:18Kg
Number of motors: 1(op)+1 motor-fans
Voltage:230v-110v-Frequency:50Hz-60Hz
Power:1(single)-Amperage: 2,1A - 4,62A
Potencia:0,30/360
Condenser: 14MF-450V - 55nf-400v
Speed:1300-1650 Protection degree:IP21
Maximum Continuous Service Time:30min.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 65mm
Duration of Grinding Wheels:500kg Cof.B.
Hopper Capacity: 2Kg.
Dispenser Capacity: 5gr-12gr
On-Off: Automatic(Movie)
On-Off:Automatic every 8 coffees-Bi.motor
Minimum Time in Repose: 10 min.
