Burst (B) Burst rate: Adjustable, 0.5 ~ 5Hz
Pulse width adjustable,
50~300μS
= dexif ycneuqerF
Normal (N) The pulse rate and pulse width are adjustable. It
generates continuous stimulation based on the
setting value.
Pulse Width
Modulation (M)
The pulse width is automatically varied in a
cycle time. The pulse width is decreased from
its original setting to 60% in setting cycle time,
and then increased from 60% to its original
setting in nest setting cycle time. In this
program, pulse rate (1 to 150Hz), pulse width
(50 to 300us) and cycle time (5 to 30 sec) are
fully adjustable.
Pulse Rate
Modulation (M1)
The pulse rate is automatically varied in a cycle
time. The pulse rate is decreased from its
original setting to 60% in setting cycle time, and
then increased from 60% to its original setting in
nest setting cycle time. In this program, pulse
rate (1 to 150Hz), pulse width (50 to 300us) and
cycle time (5 to 30 sec) are fully adjustable.
10μS/step
100 Hz
