Current Solutions InTENSity Select Combo - Page 19

TENSPros
Technical specifications for Electrical Muscle Stimulation
(EMS) mode
Waveform: Mono-
p
hase s
q
ua
r
e
p
ulse wave
Pulse amplitude Adjustable, 0~105mA peak at 1000 ohm Load
each channel, 1mA/Step.
Pulse Width Adjustable, from 50 to 300μS microseconds,
10
μ
S/ste
p
.
Pulse Rate Adjustable, from 1 to 150 Hz, 1 Hz/step
Contraction time Adjustable, 1~60 seconds , 1 Sec./ step
Relaxation (OFF) Adjustable, 0~60 seconds , 1 Sec./ step
Ramp time Adjustable, 1~6 seconds, 1 Sec. / step, The
“On” time will increase and decrease in the
setting value.
Synchronous (S) Stimulation of both channels occurs
synchronously. The“ON” time including
“Contraction”, “Ramp Up” and “Ramp Down”
time.
ON TIME=Contraction + Ramp up + Ramp
dow
Alternate (A) The Stimulation of the CH2 will occur after the
1st working of CH1 is completed. In this
program, The “ON” time including “Contraction”,
“Ramp Up” and “Ramp Down” time. The OFF
Time should be equal or more than the ON
Ti
TI
Ramp down
OFF TIME≥ON TIME
Delay (D) The Stimulation of the CH2 will occur after the
1st operation of CH1 is started+ Delay Time. In
this program, The “ON” time including
“Contraction”, “Ramp Up” and “Ramp Down”
time. The OFF Time should be equal or more
than the ON Time + Delay Time.
ON TIME=Contraction + Ramp up + Ramp
down
