Technical specifications for Interferential (IF) mode
Waveform Bi-phase square pulse
Pulse amplitude Adjustable, 0~70mA peak to peak at 1000 ohm Load
Pulse Rate Channel 1 – Fundamental frequency: 4000 Hz fixed
Channel 2 – Selectable frequency: 4001 to 4150 Hz
Interference frequency: 1 to 150 Hz.
Phase Width 125μS
Technical specifications for Microcurrent (MIC) mode
Waveform Mono-phase square pulse wave
Pulse amplitude Adjustable, 0~0.7mA peak at 1000 ohm Load each
channel
0.01mA/Ste
p
Pulse Width (P.W.) Adjustable, from 2 to 200ms, 1ms/step
Pulse Rate (P.R.) Adjustable, from 1 to 150 Hz, 1 Hz/step
Constant(P1) Constant stimulation based on setting value. Only
pulse width, pulse rate and timer are adjustable in
this program. “Constant” is equal to the “Normal”
mode of a TENS therapeutic mode
Pulse Width
Modulation (P2)
The pulse width is automatically varied in a cycle
time.The pulse width is decreased from its original
setting to 60% in setting cycle time, and then
increased from 60% to its original setting in nest
setting cycle time. In this program, pulse rate (1 to
150Hz), pulse width (2 to 200ms) and cycle time (5 to
30 sec) are fully adjustable.
Pulse Rate
Modulation (P3)
The pulse rate is automatically varied in a cycle time.
The pulse rate is decreased from its original setting
to 60% in setting cycle time, and then increased from
60% to its original setting in nest setting cycle time. In
this program, pulse rate (1 to 150Hz), pulse width (2
to 200ms) and cycle time (5 to 30 sec) are fully
adjustable.
