REAR VEHICLE ACCESS
Figure 9
Remove the security pins from the base of the bike rack and replace them in the top hole of the base plate so the carrier
does not tip too far down. See Figure 9, Detail O. Tilt the carrier down until it is supported by the security pins. See Figure 9.
Detail O
