curt DISCOVERY 51126 User Manual

CURTMFG.COM
•
PRODUCT SUPPORT: 877.287.8634
•
51126-INS-RA
•
PAGE 2
1. Main module with CURT quickplug
2. Mounting Bracket
3. Mounting Screws
4. Base plate adhesive pad
5. Cable ties
1. Drill
2. Drill bit, 1/8"
3. Phillips screwdriver
4. Pry tool
CONTROLS & COMPONENTS
TOOLS LIST
2
3
4
5
1
TABLE OF CONTENTS
Controls & Components
Tools List
Before You Begin
Controls
Wiring
Wiring the Controller
Wiring Diagram
Mounting the Brake Controller
Modes & Indicators on the LED Display
Initial Setup
Test Drive & Adjustment
Bench Test
Troubleshooting Guide
page 2
page 2
page 3
page 3
page 4
page 4
page 5
page 6
page 7
page 11
page 12
page 12
page 14

curt DISCOVERY 51126 Specifications

General

Brand	curt
Model	DISCOVERY 51126
Category	Controller
Language	English
