1313 Handheld Programmer Manual (18 MARCH 2010)
1 5 M A R C H 2 0 1 1 D R A F T
2 — OPERATION
+/- keys
These two keys allow you to increase or decrease the value of parameter set-
tings. They also are used as “+ = Yes” and “- = No” buttons. In some cases,
they are used to scroll through several options (as in selecting an access level,
or selecting a language).
Power
It is not necessary to use the Power key to turn on the programmer when you
plug it into an active control system; it will turn on automatically.
To turn off the programmer, press and hold the Power key for a few sec
-
onds. You will then be asked whether you want to power off the programmer,
and the softkey text will offer you the choices “Yes” and “No.”
If you have turned off the programmer, or if it has timed out and shut
itself off, pressing the Power key will turn it on again.
Favorites
This key is an alternate way to bring up the Favorites menu. You can access
the Favorites menu by selecting its icon in the Main Menu, or by using the
Favorites key. See the Favorites menu section for more information.
Screenshots
By pressing the Power key and then the Favorites key, you can take a screenshot
of the LCD display; see Section 13.
Main Menu
This key will return you directly to the Main Menu, from wherever you are.
When the Main Menu is displayed, you can also use this key to cycle through
the individual menus. You can use either this key or the arrow keys to navigate
within the Main Menu, whichever you prefer.
Help
This key is used to display context-specific Help texts. It is a toggle key; you
can press it again to close the Help text window. You can also close Help text
windows with the “Exit” softkey or by pressing the left-arrow key.
