2 — INSTALLATION AND WIRING
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 24
Motor Temperature Input
e traction motor’s temperature sensor input measures the resistance of the connected sensor. e
controller supports KTY83, KTY84, and PT1000 temperature sensors. A parameter-VCL sensor
conguration prole allows the usage of custom solutions, with a maximum source current of less
than 2 mA. e controller is unable to use low resistance sensors, such as the PT100.
In all cases, connect the sensor’s ground/negative lead to the controller’s I/O ground (pin 18).
Table 14 Motor Temperature Sensor Specifications
Signal Pin
Temperature
• Type
Resistance
Measurement Range
Accuracy
Motor Temp 8
–40 – 200° C
KTY83,84: ±5° C
PT1000: ±15° C
250 – 5k Ω ± 20 Ω @ ≤ 2k Ω
VCL Functions VCL Monitor Variables
Motor_Temperature
MotorTempCutback
Analog_Input_Volts_2
