Curtis 700 series User Manual

54
w xx y
LED Sequential
Voltage (VDC) Code Logo
0 = 12 factory N= No Logo
1 = 24 specified O= Curtis
2 = 36
3 = 48
!
1 B. MODEL ENCODEMENT (732 only)
732 u
Case
N = Hex-shaped bezel,
with
1
/4” Faston
terminals
K = Hex-shaped bezel,
with Packard
connector
See Section 2.2 for
Specifications
Note: 732 has a built-in LED in its face
v
Function
0= 2-wire Hour Meter, no enable
LED gnd-enabled, no reset
1= 2-wire Hour Meter, no enable
LED pwr-enabled, no reset
2= 2-wire Hour Meter, no enable
LED gnd-enabled, w/reset
3= 2-wire Hour Meter, no enable
LED pwr-enabled, w/reset
4= 3-wire Hour Meter, w/enable
LED gnd-enabled, no reset
5= 3-wire Hour Meter, w/enable
LED pwr-enabled, no reset
