Impedance
The minimum impedance at terminal 3 and at
terminal 4 are tabulated below for each model.
Voltage Impedance (Min) Impedance (Min)
Encodement Terminal 3 Terminal 4
0512D 10 KΩ 25 KΩ
1248D 60 KΩ 70 KΩ
48150D 480 KΩ 480 KΩ
0512D 0612A 10 KΩ 25 KΩ
1248D 2060A 70 KΩ 70 KΩ
48150D 100230A 480 KΩ 480 KΩ
732 (all voltages) – 70 KΩ
2.2 Mechanical
Display 6-digit LCD, 5 mm high
Range & Resolution
700, 701, 732 Hour Meters 703 Counter
99,999.9 Hours 999,999 Counts
!
!
