2. TECHNICAL SPECIFICATIONS
2.1 Electrical
Operating Voltage 700 Series
The operating voltage ranges specified apply to voltages
connected between terminal 1 and terminal 2 (700,701,703),
terminal 3 and terminal 2 (701,703 only), and terminal 4 and
terminal 2 (Reset option).
1. DC Only Models:
Nominal (VDC) Absolute (VDC)
5 to 12 4.75 to 15
12 to 48 9.0 to 60
48 to 150 36 to 185
2. DC/AC Models:
Nominal (VDC) Absolute (VDC)
Same As Above
Nominal (VAC) Absolute (VAC)
6 to 12 5.0 to 15
20 to 60 15 to 75
100 to 230 75 to 270
!
732 Only
a) Voltages connected between pins 1 and 2 and
between 4 and 2 (Enable option)
3a. 732 DC only, all voltage models:
Nominal (VDC) Absolute (VDC)
12 to 48 9.0 to 60
b) LED voltages betweeen pins 3 and 2
3b. 732 LED voltages: Absolute (VDC)
12 9 to 15
24 18 to 30
36 27 to 45
48 36 to 60
Frequency (AC models)
The AC operating frequency range is 48 to 440 Hz.
Maximum AC-Reset Frequency is 150 Hz.
Accuracy
Model 700, 701, 732 = ±0.1%
Model 703 = ±1 count
!
