Curtis 700 series User Manual

14
2.3 Environmental
Temperature
Operating: -40°C to +85°C
Storage: -50°C to +90°C
Humidity 95% RH (Non Condensing) at 38°C
Shock &
Vibration Meets SAE J 1378
Case - IP Ratings
!
15
3. INSTALLATION
V+ Operating voltage
V– Common (ground)
I Enable (optional, use operating voltage to power this pin
to record elapsed time (701) or increment count (703))
R Reset (optional, supply with operating voltage when unit
is to be reset to 0)
LED – Externally driven by active high or low – factory
configured
NC No connection
!
Case Style Pin 1 Pin 2 Pin 3 Pin 4
D, F, Q,
R , J, Y, Z V+ V– I R
G, H V+ V– NC NC
L V+ V– I NC
K, N V+ V– LED I
Case Style D, Q, R F, Z, N G, J,Y, H, K L
Front 65 65 65 65
Rear 50 65 *65 40
*Note: Rated with mating connector installed
