Curtis 700 series User Manual

Case & Connector Specifications
Note: K & N - LED indicator molded in bezel face (available as 732 models only)
G & H - Require 2-pin Delphi- Packard mating connector P/N 12162000
J, K & Y - Require 4-pin Delphi- Packard mating connector P/N 12162035
L - Snap tabs built in(no mounting hardware required); case and bezel 1-piece clear
Hexagonal - Screw mount through flange (optionally mounted with plastic bracket, available separately)
12
!
13
Case Bezel Shape Terminals Max Pins Mounting Lens Matrl. Case Matrl. Bezel Matrl. Panel Cutout (mm) Panel Cutout (in)
F Hexagonal
1
/4” Faston 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
G Hexagonal Packard 2 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
J Hexagonal Packard 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
K Hexagonal Packard 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
N Hexagonal
1
/4” Faston 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
D Rect.-DIN
3
/16” Faston 4 U-bracket Acrylic ABS (black) ABS (black) 45x22.2 1.77x0.87
L Rectangular Molex-mini 4 Snap-in Polycarb. Polycarb. Polycarb. 36.8x24.1 1.45x0.95
H Rectangular Packard 2 Bracket (plast.) Acrylic ABS (black) Acrylic (clear) 36.8x24.1 1.45x0.95
Y Rectangular Packard 4 Bracket (plast.) Acrylic ABS (black) ABS (black) 36.8x24.1 1.77x0.87
Z Rectangular
1
/4” Faston 4 Bracket (plast.) Acrylic ABS (black) ABS (black) 36.8x24.1 1.77x0.87
Q Round
1
/4” Faston 4 U-bracket Glass Polycarb. Alum. Anodzd. (blk) 52 2
1
/16”
R (5mm) Round
3
/16” Faston 4 U-bracket Glass Polycarb. Alum. Anodzd. (blk) 52 2
1
/16”
