Curtis 700 series User Manual

98
Operating Current (All models except 732)
The maximum operating current at terminal 1 is tabu-
lated below for each nominal operating voltage limit.
DC Operating Maximum Maximum
Only Voltage (VDC) Current Current
Model V+ to V++ @ V+ @ V++
5 to 12 0.5 mA 10.0 mA
12 to 48 0.8 mA 5.0 mA
48 to 150 0.8 mA 2.5 mA
DC/AC Operating Maximum Maximum
Model Voltage Current Current
V+ to V++ @ V+ @ V++
VDC -
same as
above
6 to 12 VAC 0.7 mA 6.0 mA
20 to 60 VAC 0.5 mA 2.5 mA
100 to 230VAC 0.9 mA 2.0 mA
!
Operating Current (continued)
Operating Current - 732 only
Single Voltage, DC only
Operating Maximum
Voltage (VDC) Current w/LED (mA)
12 15.0
24 10.0
36 7.0
48 5.0
!
