ILLUSTRATED PARTS LIST IP33
GEMSS/GEMTS - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 090519E
ITEM # PART # DESCRIPTION
1 GEM-3 SATELLITE SERVER, 1-1/2 GAL.
2 WC-58117
COVER, TOP ALPGT/D500GT/D60GT/TLP/TCTS/
CBS/GEMSS
3A* WC-820WDR
1,3
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
3B WC-854
2
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
4A* WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
6A WC-442
1,3
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
6B WC-446
2
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
7A* WC-844-101
1,3
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
7B WC-844-102
2
VALVE, BY-PASS, 220V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
8A WC-723
1,3
CONTROL MODULE, UCM 120V TP2S /TP2T
GEMSS/GEMTS
8B WC-728
2
CONTROL MODULE, UCM 220V TP2S/ TP2T/
GEMSS/GEMTS
9A* WC-39436
LABEL, UCM OVERLAY SINGLE 3-BATCH
GEMSS CURTIS
9B* WC-39434
LABEL, UCM OVERLAY GEMSS SINGLE
2-BATCH CURTIS
9C* WC-39432
LABEL, UCM OVERLAY SINGLE 1-BATCH
GEMSS CURTIS
10* WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11 WC-61396 COVER, FRONT GEMSIF10/63/30
12 WC-39448
LABEL, BOTTOM WRAP GEMSIF INTELLIFRESH
CURTIS
13* WC-1809-P
FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF
AP/ALP
14A WC-1250
2
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END (NOT SHOWN)
14B WC-1200
3
CORD, 14/3 SJTO 6’ BLK W/PLUG
15* WC-3528
LEG, 4" ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
16 WC-5428 DECK, WARMER FORMED MINI-GEMS
17* WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
18 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
ITEM # PART # DESCRIPTION
19 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
20* WC-103
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
21A* WC-847
1,3
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
21B WC-883
2
VALVE, INLET 2 GPM 240V 10W
22* WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
23* WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
24* WC-5231 COMPOUND, HEAT SINK 5OZ
25* WC-314 POWER BLOCK, 5 STATION
26 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
27A WC-13287
1, 3
HARNESS, ASSY COMPLETE GEMSS
(INCLUDES TERMINAL BLOCK)
27B WC-13379
2
HARNESS ASSY, DV CONVERSION GEMSS/
TP2S (INCLUDES TERMINAL BLOCK)
28 WC-29044-101 SLEEVE, OVERFLOW
29A* WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
29B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
30 WC-596K
2
KIT, NOISE FILTER EMI 250V/30A 1PH
31A WC-37102
1, 3
KIT, WARMER ELEMENT 100W 120V GEN USE
31B WC-973
2
ELEMENT, WARMER ASSY 100W 220V
32A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
32B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
33A WC-4213-P
a
NUT, 5/8 LOCK PLATED
33B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
34 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
35 WC-4439 SCREW, 6-32x¼ PHIL PAN HD SS
36 WC-4412 SCREW, 10-32x3/16” PH PN HD MS SS
37 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD
STAINLESS STEEL
38 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
39 WC-62096K
KIT, COVER, PIVOTING, FRONT DISPLAY
GEMSIF (OPTIONAL ACCESSORY,
INCLUDES MOUNTING HARDWARE)
GEMSS - Main Chassis - Parts List
1
GEMSS10A10000,
2
GEMSS30A1000,
3
GEMSS63A1000
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Units built before 05/15/17.
5HFRPPHQGHGSDUWVWRVWRFN
