Curtis RU Series - Dimensional Drawings; RU-150 Series Dimensions

ROUGH-IN DRAWINGS RD44
RU-150 Series
36306()*/%3"8*/(ø /$
3.38 in
[8.6 cm]
3.25 in
[8.3 cm]
4.25 in
[10.8cm]
9.75 in
[24.8 cm]
29.25 in
[74.30 cm]
23.75 in
[60.3 cm]
16.50 in
[41.9 cm]
20.50 in
[52.1 cm]
6.38 in
[16.2 cm]
8.75 in
[22.2 cm]
19.38 in
[49.2 cm]
