ILLUSTRATED PARTS LIST IP69
RU AUTOMATIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 0031022C
RU/URN Series - Main Chassis - Parts List
ITEM # PART # DESCRIPTION USED ON
1 WC-3205 KNOB, LID 1/4-20 FEMALE THRD USE ON WC-5601/5602/5603 ALL RU UNITS
2A WC-5601 LID, LINER ASSY (SC)RU-150/300 (INCLUDES KNOB) RU-150, RU-300
2B WC-5603 LID, LINER ASSY RU225/600/1000 (INCLUDES KNOB) RU-225, RU-600, RU-1000
3A WC-5700 LINER, 3 GAL RU-150 RU-150
3B WC-5701 LINER, 3 GAL D/S RU-150 RU-150DS
3C WC-5706 LINER, 6 GAL RU-600 RU-225, RU-600
3D WC-5703 LINER, 6 GAL D/S RU-225 RU-225DS
3E WC-5707 LINER, 6 GAL D/S RU-600 RU-600DS
3F WC-5704 LINER, 3 GAL RU-300 RU-300
3G WC-5705 LINER, 3 GAL D/S RU-300 RU-300DS
3H WC-5708 LINER, 10 GAL RU-1000 RU-1000
3J WC-5709 LINER, 10 GAL D/S RU-1000 RU-1000DS
4A WC-4303 O-RING, LINER RU-150/300 RU-150, RU-300
4B WC-43076 O-RING, LINER, RU’S, 6, 10 GA RU-225, RU-600, RU-1000
5 WC-3217 KNOB, ELECTRIC THERMOSTAT RU ALL RU UNITS
6 WC-3220 BEZEL, THERMOSTAT ELECTRIC URN’S ALL RU UNITS
7 WC-3305 FLAP, WIRE BASKET RU150/300 (2 REQUIRED) RU-150, RU-300
8A WC-37165 KIT, THERMOSTAT WC-500A/501A ALL RU UNITS
8B WC-502 THERMOSTAT, CAPILLARY LWC OFF DPST OLDER 3 PHASE UNITS
9A WC-300 POWER BLOCK 3-STA 175A 600V RU’S ALL DOMESTIC AND EXPORT SINGLE PHASE UNITS
9B WC-313 POWER BLOCK, 4 STA 85A 600V EXPORT THREE PHASE UNITS
10 WC-522 THERMOSTAT, HI LIMIT HEATER CONTROL DPST 277V 40A ALL RU UNITS
11 WC-3528 LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN STYLE ALL RU UNITS
12 WC-511 THERMOMETER, DIAL RU’S ALL RU UNITS
13A WC-5313 TUBE, SPRAYARM ASSY W/NUTS RU-300 RU-150, RU-300
13B WC-5314 TUBE, SPRAYARM ASSY W/NUTS RU-600 RU-225, RU-600
13C WC-5315 TUBE, SPRAYARM ASSY W/NUTS RU-1000 RU-1000
13D WC-5310 TUBE, 5/16 ID x 1/8W SILICONE URN-300, URN-600, URN-1000
14 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD ALL RU UNITS
15A WC-5800 RING, STEAM ALL SINGLE SERVICE RU UNITS
15B WC-5458 PLATE, RING STEAM D/SERVICE SHEAR SIZE 4.00 ALL DUAL SERVICE RU UNITS
16 WC-4205 NUT, 1/4 LOCK NPS BRASS ALL RU UNITS
17 WC-2913 SPOUT OVERFLOW ALL RU UNITS
18A WC-5810 COVER, W/A ELECTRIC BOX RU’S RU-600,1000 RU-150, RU-600, RU-225, RU-1000
18B WC-58067 COVER, W/A ELECTRIC BOX RU-300 RU-300
19A WC-43123 O’RING, .549 ID X .103CS SILICONE FOR HEATING ELEMENT ALL RU UNITS
19B WC-4305 WASHER 5/8” TEFLON OLDER UNITS
20A WC-431 CONTACTOR, 120V 60A 3P DP ALL DOMESTIC RU UNITS
20B WC-439 CONTACTOR, 220V 3POLE 63A RES EXPORT SINGLE PHASE UNITS
20C WC-443 CONTACTOR, 3POLE 50A 208-240VAC COIL EXPORT THREE PHASE UNITS
21A WC-3302 BREW BASKET WIRE W/FLAPS RU-300 RU-150, RU-300
21B WC-3303 BREW BASKET, WIRE W/ FLAPS RU-600 RU-225, RU-600
21C WC-3304 BREW BASKET, WIRE W/ FLAPS RU-1000 RU-1000
22A WC-13501 HARNESS ASSY, CONTROL CIRCUIT RU-300/600/1000 ALL RU UNITS
22B WC-13501-101 HARNESS ASSY, CONTROL CIRCUIT URN-300/600/1000 URN-300, URN-600, URN-1000
CONTINUED ON FOLLOWING PAGE
