Cap Constructions
Standard Material & Material for Corrosive/Low
Temperature Service - Stainless Steel
Cap
Description
Part Name
Std. Materials
S1, N1
-20°F to 800°F
S3
-75°F to
800°F
S4
-450 °F to
450°F
Packed Lever
Cap Carbon Steel 316 St. 316 St.
Test Lever Carbon Steel
Cam 316 St. St.
Cam Shaft 316 St. St.
Gland 316 St. St.
Stem Jam Nut 316 St. St.
Stem Test Nut 316 St. St.
Packing Ring Graphite
Plain Washer Steel
Lever Hex. Jam Nut Steel
Cap Stud Alloy Steel
Stainless
Steel
Stainless
Steel
Cap Hex. Nut Alloy Steel
Stainless
Steel
Stainless
Steel
Open Lever
(Single or
Double Acting)
Cap Iron
Test Lever Iron
Test Lever Fork Iron
Stem Jam Nut 316 St. St.
Stem Test Nut 316 St. St.
Cap Screw Steel, Plated
Fork Rd. Hd. Rivet Steel
Lever Rd. Hd. Rivet Steel
Cotter Pin Steel, Plated
Table D.1
