REFRESHER UNIT
33
• 18” Module and 12” Center Module
• 12" Center: The shelf insert can be adjusted for custom compartment spacing or removed completely from
the module. Each 12" module comes equipped with two shelves.
• 18" Center: The shelf inserts can be adjusted for custom compartment spacing or removed completely from
the module. Each 18" module comes equipped with two shelves.
• 6” Pull Out Module
• Hanger Inserts: There are removable hanger
inserts located inside the 6" pull out module.
The hangers can be positioned as desired fol-
lowing the hole inserts provided on board.
• Basket: There are also two removable baskets
that can be positioned as desired following the
hole inserts provided on board.
• Side Drawer
• Tray Insert: Located inside the side drawer is an alu-
minum storage tray that slides from side to side for
easy maneuverability.
Shelving
To remove shelf:
1. Push/pull up
2. Then push down slightly to release shelf
Movable Baskets
Hangers can be moved to any
location for custom layout.
Optional tray insert sits
on top of drawer and
slides back and forth.
Side drawers are removable for engine access.
See EMISSIONS LABELS ANDENGINE ACCESS.
