12
If the mobile scaffold tower is placed against a wall, do not remove the outrigger /
stabilizer, but turn it parallel to the wall. If the mobile scaffold tower is placed at an
angle, remove the inner outrigger / stabilizer, and turn the outer two parallel to the
wall.
scaffold tower with stabilizers
Mobile scaffold tower with outriggers
Positions of stabilizers or
Outrigger
Stabilizer
